Johnson Controls VG1245BN+943GGA Two-Way NPT Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1245BN+943GGA includes a stainless steel two-way NPT ball valve and a VA9203-GGA-2Z electric actuator. This valve assembly is specially designed to control the flow of hot or chilled water, and in some instances, low-pressure steam in HVAC systems.

• Includes the VG1000 Series two- and three-way forged brass valves.
• Compatible with Johnson Controls VA9104, M9106, M9109, and M9100 Series Non-Spring Return Actuators.
• Designed for use in sizes ranging from half an inch to two inches.

Product Highlights

Engineered for both on/off and proportional flow control, this valve assembly enhances system responsiveness and efficiency. The electric actuator included does not require a spring return and offers reliable operation.

Product Information

Standard Information

• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Position Feedback: 0 (2) to 10 VDC
• Electrical Connections: 120 inches 19 AWG Plenum Cable

Technical Specifications

• Static Pressure Rating: 580 psig
• Close Off Pressure: 200 PSID
• Body Material: Forged Brass
• Flow Capacity (Cv): 11.7
• Fluid Temperature Range: -22 to 212 degrees Fahrenheit
• Connection Type: Threaded
• Actuator Type: Proportional, non-spring return, electric
