Johnson Controls VG1245ANH943GGA Two-Way Stainless Steel Trim NPT Ball Valve 24V PROP SR

Product Description

The Johnson Controls VG1245ANH943GGA two-way stainless steel trim NPT ball valve with a 24V prop SR actuator is your go-to solution for regulating the flow of water and low-pressure steam in HVAC systems.

• Designed for hot and chilled water applications
• Compatible with various Johnson Controls actuators
• Handles static pressure of up to 580 psig

Product Highlights

This valve is part of the VG1000 series, which includes two- and three-way forged brass valves. These valves are either factory or field mounted to Johnson Controls electric actuators for on/off, floating, or proportional control. It is available in sizes ranging from 1/2 to 2 inches.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• MPN: VG1245ANH943GGA
• Brand: Johnson Controls
• Category: HVAC Controls

Technical Specifications

• Valve Size: 1/2 inch
• Flow Rate: 11.7 Cv
• Power: 24V
• Static Pressure Rating: 580 psig
• Actuator Type: Electric, Non-Spring-Return
• Body Material: Forged Brass
