Johnson Controls VG1241FS+938GGC Ball Valve Assembly, 2 Way, 2 in.

Product Description

The Johnson Controls VG1241FS+938GGC is a two-way ball valve assembly designed for HVAC applications. This valve features a forged brass body and chrome plated brass ball. It operates effectively in both chilled and hot water systems with a fluid temperature range from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit.

• Maintenance-free design for operational reliability
• Performs over two hundred thousand full stroke cycles in contaminated water
• Features a direct mount electric actuator with a spring return

Product Highlights

The VG1241FS+938GGC valve provides precise control under varying load conditions and is suitable for use in hot water, chilled water, and 50/50 glycol solutions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241FS+938GGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 2 x SPDT
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F (-40 C To 60 C)
• Electrical Connection: 48 in. 18 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
