Johnson Controls VG1241ES+958GGC Ball Valve Assembly 2 Way 1-1/2 in.

Product Description

The Johnson Controls VG1241ES+958GGC is a two-way ball valve assembly designed for HVAC control. This assembly features a forged brass body that ensures durability and efficient operation. It is suitable for chilled and hot water applications.

• Maintenance-free design
• Operates efficiently at fluid temperatures from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit
• Rated for over two hundred thousand full stroke cycles

Product Highlights

This valve provides precise control in various load conditions. It handles both chilled and hot water, making it versatile for different HVAC systems.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241ES+958GGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 2 x SPDT
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F
• Electrical Connection: 48 in. 18 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
