Johnson Controls VG1241ER928AGA Ball Valve Assembly 2 Way 1-1/2 in.

Product Description

The Johnson Controls VG1241ER928AGA is a two-way ball valve assembly designed for efficient control of hot and chilled water systems. This valve features a forged brass body that ensures durability and reliability in various applications.

• Maintenance-free design
• Wide fluid temperature range from 23 F to 203 F
• Performs in excess of 200,000 full stroke cycles

Product Highlights

This valve is suitable for both chilled water and hot water applications, making it versatile for different HVAC systems.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241ER928AGA

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F
• Electrical Connection: 120 in. 19 AWG Appliance Cable
• Spring Return Torque: 70 lb-in
