Johnson Controls VG1241ER+958GGC Ball Valve Assembly 2 Way 1-1/2 in.

Product Description

The Johnson Controls VG1241ER+958GGC is a two-way ball valve assembly designed for HVAC applications. This model features a one and one-half inch size and is ideal for both hot and chilled water systems.

• Maintenance-free design
• Performs reliably for over 200,000 full stroke cycles
• Compatible with fluid temperatures from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit

Product Highlights

This ball valve assembly offers accurate control in various load conditions, utilizing chrome-plated brass components for durability

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241ER+958GGC

Technical Specifications

• Flow Coefficient (Cv): 29.2
• NPT Connection: Yes
• Power Supply: 24 VAC
• Operating Conditions: -40 F to 140 F
• Close-Off Pressure: 200 psig
• Electrical Connection: 48 in. 18 AWG cable
• Auxiliary Switch: 2 x SPDT
• Service Type: Hot Water, Chilled Water, 50/50 Glycol Solution
