Johnson Controls VG1241ER+938GGC Ball Valve Assembly, 2 Way, 1-1/2 In.

Product Description

The Johnson Controls VG1241ER+938GGC is a two-way ball valve assembly, designed for reliable operation in HVAC systems. This assembly features a one and a half inch connections and a maintenance-free design. It is suitable for both hot and chilled water applications, ensuring versatility in various environments.

• Flow Capacity: 29.2 Cv
• Temperature Range: 23 F to 203 F
• Direct Mount Electric Actuator with 70 lb-in. Spring Return

Product Highlights

This valve assembly performs without failure in excess of 200,000 full stroke cycles, making it suitable for demanding conditions. It operates efficiently across a fluid temperature range and ensures accurate control under varying load conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241ER+938GGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 2 x SPDT
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F to 140 F
• Electrical Connection: 48 In. 18 AWG Appliance Cable with Integral 3/8 In. FMC Connectors
