Johnson Controls VG1241EP948AGA Ball Valve Assembly, 2 Way, 1-1/2 in.

Product Description

The Johnson Controls VG1241EP948AGA is a reliable ball valve assembly designed for two-way operation. This valve has a size of one and a half inches. It features a maintenance-free design and delivers 18.7 Cv for efficient flow control. The assembly is suitable for both chilled and hot water applications.

• Forged brass body for durability
• Chrome plated brass ball
• Spring return actuator designed for 24 VAC operation

Product Highlights

This product is built to endure over 200,000 full stroke cycles in challenging water conditions. Its construction allows it to manage a fluid temperature range of twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1241EP948AGA

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F to 140 F (-40 C to 60 C)
• Electrical Connection: 120 in. 19 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
