Johnson Controls VG1241EP928AGA Ball Valve Assembly 2 Way 1-1/2 in.

Product Description

The Johnson Controls VG1241EP928AGA is a reliable ball valve assembly designed for two-way control in HVAC systems. It has a one and one-half inch connection and is built for both chilled and hot water applications. With its durable forged brass body and chrome-plated ball, this valve ensures long-lasting performance. The valve is equipped with a direct mount electric actuator, providing ease of installation and integration with various control systems.

• Maintenance-free design with over 200,000 full stroke cycles.
• Handles both chilled and hot water with a temperature range of twenty-three to two hundred three degrees Fahrenheit.
• Features an equal percentage flow characteristic for precise control.

Product Highlights

This ball valve is suitable for controlling liquid flow in demanding HVAC applications, ensuring efficient operation and minimal maintenance.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241EP928AGA

Technical Specifications

• Flow Coefficient (Cv): 18.7
• Close-Off Pressure: 200 psig
• Power Consumption: 7.9 VA running, 5.5 VA holding
• Electrical Connection: 120 inches, 19 AWG appliance cable
• Operating Conditions: -40°F to 140°F
• Service Type: Hot water, chilled water, 50/50 glycol solution
• Housing: NEMA 2, IP54
• Flow Characteristic: Equal Percentage
