Johnson Controls VG1241DR+958GGC Ball Valve Assembly, 2 Way, 1-1/4 in.

Product Description

The Johnson Controls VG1241DR+958GGC is a two-way ball valve assembly designed for reliable flow control. This assembly is suitable for both chilled and hot water applications, accommodating a fluid temperature range from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit.

• Maintenance-free design
• Performs over 200,000 full stroke cycles
• Handles chilled and hot water applications

Product Highlights

The valve features a forged brass body and chrome-plated brass ball. It integrates a nickel-plated brass blowout-proof stem for added durability. The direct mount electric actuator operates on twenty-four volts AC and provides proportional control.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241DR+958GGC

Technical Specifications

• NPT Size: 1-1/4 in.
• Flow Coefficient (Cv): 29.2
• Power Requirements: 24 VAC and 0 to 10 VDC
• Spring Return Torque: 70 lb-in.
• Flow Characteristic: Equal Percentage
• Auxiliary Switch: 2 x SPDT
• Close-Off Pressure: 200 psig
• Operating Conditions: -40 F to 140 F (-40 C to 60 C)
• Electrical Connection: 48 in. 18 AWG appliance cable
• Service Compatibility: Hot Water and Chilled Water
• Housing Rating: NEMA 2, IP54
