Johnson Controls VG1241DP+958BAA Ball Valve Assembly, 2 Way, 1-1/4 in.

Product Description

The Johnson Controls VG1241DP+958BAA is a two-way ball valve assembly designed for various HVAC applications. It features NPT connections and is constructed from forged brass. This valve can handle both chilled and hot water systems, making it versatile for different environments.

• Maintenance-free design with a long operational lifespan
• Handles fluid temperatures ranging from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit
• Integrates a direct mount electric actuator with spring return capabilities

Product Highlights

This ball valve assembly is engineered for reliability and efficient control, ensuring performance even in challenging conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241DP+958BAA

Technical Specifications

• Power Consumption: 0.05 A Running, 0.03 A Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F (-40 C To 60 C)
• Electrical Connection: 48 in. 18 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Housing: NEMA 2, IP54
