Johnson Controls VG1241AE+9T4GGA Valve NPT End Connections Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1241AE+9T4GGA is a robust ball valve designed for HVAC systems to regulate the flow of hot or chilled water and low-pressure steam. This valve, equipped with the VA9104 non-spring return electric actuator, offers precise control in a compact form.

• Efficient temperature regulation in HVAC systems.
• Durable forged brass body capable of handling pressures up to 580 psig.
• Conveniently packaged with dimensions, facilitating easy installation with minimal space requirements.

Product Highlights

This Johnson Controls valve assembly is ideal for professionals in the HVAC field seeking reliability and precise control. The inclusion of the VA9104 actuator allows for both on/off and proportional control settings, suitable for a wide range of applications.

Technical Specifications

• Material: Forged Brass
• Connection Type: NPT threaded
• Pressure Rating: 580 psig
• Actuator Type: VA9104, non-spring return
• Control Type: On/off, floating, proportional
• Size: 1/2 inch NPT
• Weight: 0.6 lbs
• Dimensions: 6.0 inches by 5.0 inches by 6.0 inches
