Johnson Controls VG1241AE+943BUA Two-Way Ball Valve Electric Actuator

Product Description

The Johnson Controls VG1241AE+943BUA model encompasses a precision-engineered Two-Way Plated Brass Trim Ball Valve, integrated with a VA9203-BUA-2 Electric Actuator. This valve is expertly designed for regulating the flow of hot or chilled water, and in specific models, low-pressure steam within HVAC systems.

• Optimized for use with several Johnson Controls actuators for diverse control scenarios.
• Facilitates sizes from half an inch to two inches, suitable for a variety of piping standards.
• Engineered for both durability and performance.

Product Highlights

This model is fully compatible with VA9104, M9106, M9109, and M9100 series Non-Spring-Return and VA9203 and VA9208 Series Spring-Return Electric Actuators, providing versatile implementation options in on/off, floating, or proportional control setups.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1241AE+943BUA

Technical Specifications

• Body Material: Forged Brass
• Pressure Rating: 580 psig static
• Size Range: 0.5 to 2 inches
• Type: Two-Way Plated
• Connection Type: NPT End Connections
• Actuator Model: VA9203-BUA-2
