Johnson Controls VA9208-GGC-3 VA9208 Series On/Off and Floating Electric Spring-Return Actuator 24 VAC 150 S Prop SR 2AuxSw

Product Description

The Johnson Controls VA9208-GGC-3 is a 24 VAC electric actuator used for precise control in HVAC systems. This model is part of the VA9208 Series featuring spring-return and floating control capabilities. It is ideal for direct mounting on Johnson Controls VG1000 Series valves including one and one-quarter, one and one-half, and two-inch ball valves.

• Direct mounting with a single screw
• Electronic stall detection for improved efficiency
• Microprocessor-controlled brushless DC motor

Product Highlights

The actuator gives accurate positioning and includes dual auxiliary switches for added functionality. It ensures reliable performance in demanding HVAC applications.

Product Information

Standard Information

• Brand: Johnson Controls
• Model: VA9208-GGC-3

Technical Specifications

• Voltage: 24 VAC
• Torque: 120 ft-lb
• Stroke Time: 150 seconds
• Auxiliary Switches: 2
• Spring Return: Yes
• Construction: Double-insulated
• Dimensions: 8.25 x 6.3 x 4.55 inches
• Weight: 4.1 lbs
