Johnson Controls VA9208-GGA-3 Electric Spring-Return Actuator 24V

Product Description

The Johnson Controls VA9208-GGA-3 Electric Spring-Return Valve Actuator ensures reliable control of HVAC valve functions. This model is engineered for direct mounting on Johnson Controls VG1000 Series ball valves, simplifying installation and setup.

• Supports valve sizes from 1-1/4 to 2 inches for versatile application.
• Features electronic stall detection and a microprocessor-controlled brushless DC motor.
• Constructed with double insulation and includes a spring-return mechanism to maintain position in the event of power loss.

Product Highlights

This actuator is designed for both on/off and floating point operations and is compatible with 24V AC power setups. The robust mechanical spring-return system ensures the actuator maintains the valve position even without power. An optional line voltage auxiliary switch enables additional functionality, such as signaling end-stop position or performing other switch operations.

Product Information

Technical Specifications

• Weight: 3.74 lbs
• Electrical Connection: 48-inch leads with an Integral 3/8-inch FMC connector
• Control Signal Compatibility: 0 to 10 VDC or 2 to 10 VDC, optionally 0 to 20 mA or 4 to 20 mA with resistor
• Operational Voltage: 24V AC
• Rotation: Provides rated torque with and without power
