Johnson Controls VA7810-HGA-2 VA7800 Series Electric Valve Actuator, 6 VA Rating

Product Description

The Johnson Controls VA7810-HGA-2 is part of the VA7800 Series Electric Valve Actuator designed for precise control of VG7000 Series Bronze Globe Valves in HVAC systems. This actuator produces a minimum linear output force of 180 lb (800 N) and can be mounted in the field or coupled at the factory to valves ranging from one half inch to two inches.

• Automatic stroke adjustment for easy commissioning.
• Manual override for simple valve positioning during service.
• IP54 enclosure for resilience in varied environments.

Product Highlights

This actuator features a unique swing-gate yoke for secure valve attachment and a brushless motor for energy efficiency and longevity. It is compatible with both spring-return and non-spring-return systems, allowing flexibility in HVAC applications.

Product Information

Standard Information

• Brand: Johnson Controls
• Item Number: VA7810-HGA-2

Technical Specifications

• Torque: 225 lb-in
• Voltage: 24v
• VA Rating: 6
• Weight: 7 pounds
• Actuator Type: Floating Point, Proportional, On/Off
• Fail Safe Mode: Non-Spring Return
