Johnson Controls V146GL1-001C Water Regulating Valve Two-Way 1 Inch Union Sweat

Product Description

The Johnson Controls V146GL1-001C Water Regulating Valve is a two-way, pressure-actuated valve designed for water flow regulation and refrigerant head pressure control in systems with water-cooled condensers. It is suitable for high-rise buildings with system water pressures up to 350 psig.

• Regulates water flow to control refrigerant head pressure
• Works with system pressures up to 350 psig
• Ideal for high-rise building applications

Product Highlights

Designed for efficient water flow regulation and head pressure control in HVAC systems.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• Brand: Johnson Controls
• Model Number: V146GL1-001C

Technical Specifications

• Product Type: Water Regulating Valve
• Valve Type: 2 Way
• Connection Type: Sweat
• Port Size: 1 inch
• Minimum Fluid Temperature: -4 Degrees F
• Design Pressure: 630 psig
• Set Points: 200 to 400 psig
• Application: Head Pressure Control with Non-Corrosive Refrigerants
• Repair Kit: STT17A-622R
• Replacement Cartridge: SEP38A-603R
