Johnson Controls V-3766-1003 Pneumatic Flare Valve 1/2 Inch Size Brass

Product Description

The Johnson Controls V-3766-1003 Pneumatic Flare Valve is engineered for reliable operation in HVAC systems. This valve is designed with a 1/2 inch flare connection, suitable for regulating the flow of water in various industrial applications.

• 1/2 inch SAE 45 flare connections for easy maintenance without soldering.
• Built with non-adjustable ring pack packings for long-lasting durability.
• Capable of handling pressures up to 400 psig, ensuring broad compatibility.

Product Highlights

The valve features a two-way, normally-open configuration with a 3-6 psi spring range and a maximum flow rate of 3.2 CV, making it ideal for applications requiring precise flow control. Each unit is thoroughly tested to guarantee tight shutoff for enhanced energy efficiency and occupant comfort.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: V-3766-1003

Technical Specifications

• Material: Brass
• Connection Type: Flare
• Size: 1/2 inch
• Pressure Rating: 150 psi WOG
• Weight: 2.90 lbs
• Valve Type: 2-Way
• Flow Coefficient (Cv): 3.2
• Product Configuration: Straight
