Johnson Controls T-5210-2005 pneumatic temperature transmitter 4 ft. copper capillary -15 to 35C operating range

Product Description

The JOHNSON CONTROLS T-5210-2005 is a pneumatic temperature transmitter designed for precise temperature control. It measures temperature and converts it into an air pressure signal for pneumatic receivers or controllers. Featuring a copper bulb element with a 4 ft. copper capillary, it operates within a -15 to 35 degrees Celsius range. This transmitter provides an exact proportional relationship between measured temperature and the transmitted signal.

• Provides an exact proportional relationship between the measured temperature and the transmitted signal
• Includes appropriate brackets for mounting to ductwork, walls, or directly to a duct flange
• Operates in any position from a rigid, flat mounting surface

Product Highlights

Precise pneumatic temperature measurement with a 4 ft. copper capillary and -15 to 35 C operating range.

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: T-5210-2005

Technical Specifications

• Operating Temperature Range: -15 to 35 Deg C
• Element Style: Copper Bulb with 4' Capillary
• Bulb Material: Copper
• Capillary Length: 4 ft (1.2 m)
• Capillary Material: Copper
• Element Temperature: -40 to 230 Degree
• Output Pressure Range: 3 to 15 Psig
• Air Consumption and Output Flow Capacity: 45 SCIM
• Supply Pressure: 20 Psig
