Johnson Controls T-3311-1 Combination Thermostat/ Valve Actuator

Product Description

The Combination Thermostat/ Valve Actuator from Johnson Controls, model T-3311-1, is designed for controlling valve operations in air conditioning units. It provides direct acting pressure of fifteen pounds per square inch and reverse acting pressure of twenty pounds per square inch.

• Fits any Johnson Controls half inch to two inch normally open, normally closed, or mixing valve that accepts a V-3000 actuator.
• Includes a protective snap-on cover for enhanced durability.
• Equipped with a liquid-filled bulb for precise temperature measurement.

Product Highlights

This actuator is suitable for valve-controlled terminal air conditioning systems, ensuring reliable operation and easy integration.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: T-3311-1

Technical Specifications

• Operating Pressure: Direct Acting 15 psig, Reverse Acting 20 psig
• Compatibility: Fits valves from 0.5 inches to 2 inches
• Temperature Measuring Element: Liquid Filled Bulb
• Setpoint Adjustment: External
• Cover Type: Protectively Snap-On
