Johnson Controls T-3300-2 Dual Temperature Dual Pressure Thermostat 60 to 150 Deg F

Product Description

The Johnson Controls T-3300-2 is a dual temperature dual pressure thermostat with a temperature range of 60 to 150 Deg F (16 to 66 Deg C). It features DIR action at 20 psig and REV action at 15 psig. Designed with a bulb element, external setpoint adjustment, and remote mount capability. Ideal for heat and cool applications with high volume airflow.

• Dual Temperature Dual Pressure Thermostat
• Application Heat and Cool
• Air Flow Output High Volume

Product Highlights

Dual temperature, dual pressure thermostat with remote bulb sensor and external setpoint adjustment.

Product Information

Standard Information

• Brand: Johnson Controls
• Manufacturer Part Number: T-3300-2
• Country of Origin: Mexico

Technical Specifications

• Temperature Range: 60 to 150 Deg F (16 to 66 Deg C)
• Action: DIR at 20 psig, REV at 15 psig
• Element: Bulb Element
• Setpoint Adjustment: External
• Mount: Remote Mount
• MPN: T-3300-2
• Brand: JOHNSON CONTROLS
• MFR #: T-3300-2
• Air Connection Outside Diameter: 1/4 in
• Capillary Length: 42 in
• Item: Pneumatic Thermostat
• Application: Heat and Cool
• Air Flow Output: High Volume
• Number of Pipes: 2
• Control Air Pressure Settings: 15 psig (Day)/ 20 psig (Night)
• Number of Dials: Single
• Temperature Settings: Dual Temperature
• Pneumatic Thermostat Type/Indexing Switch: Remote-Bulb Sensor
• Sensor Type: Remote Bulb
• Maximum Control Temperature: 150 Degrees F
• Thermostat Action: Direct - 20 psig, Reverse - 15 psig
• Temperature Control Range: 60 Degrees to 150 Degrees F
• Mounting Direction: Vertical
• Dial Configuration: Warm/Cold
• Maximum Air Pressure: 25 psig
• Housing Material: Aluminum
• Fitting Connection: 1/4 in
• Minimum Control Temperature: 60 Degrees F
• Manual Indexing Switch: No
• Temperature Scale: Celsius/Fahrenheit
