Johnson Controls R310AD-1C Current Sensing Switch 0 to 30 VAC

Product Description

The Johnson Controls R310AD-1C current sensing switch provides reliable current detection without being directly connected to the circuit. This switch is suitable in situations where AC flow needs monitoring. It replaces the R10A and is compatible with Johnson Controls/PENN time delay oil failure cutout controls like the P28, P45, and P445. It features a high dielectric material for mounting inside a starter or contactor.

• Monitors current without circuit connection
• High dielectric material
• Compatible with various Johnson Controls models

Product Highlights

Small switch size allows installation in confined spaces. Solid-state switching removes moving parts, ensuring durability. It has a low activation threshold and can monitor heavy-duty equipment.

Product Information

Standard Information

• Brand: Johnson Controls
• Model: R310AD-1C

Technical Specifications

• Input Voltage: 0 to 30V AC/DC
• Contact Form: SPST-NO
• Contact Rating (AC): 10 A @ 260V
• Contact Rating (DC): 5 A @ 30V
• Trip Point: 0.50 A
• Mounting Style: Surface
• Sensing Hole Diameter: 0.7 in
• Body Dimensions: Depth 0.88 in, Width 1.85 in, Height 2.34 in
• Compatible Models: P28, P445, P45
