Johnson Controls P599VCPS105K Electronic Pressure Transducer 0 To 500 psi

Product Description

The Johnson Controls P599VCPS105K electronic pressure transducer features a pressure range of zero to five hundred psi and a one quarter inch SAE 45 F internal flare pressure port with depressor. This transducer is suitable for use in commercial and industrial refrigeration and air conditioning applications. It generates a proportional analog signal based on the sensed pressure.

• Industrial design includes a snubber for dampening pressure pulsations and avoids the use of O-rings.
• Rated for over ten million full-scale pressure cycles.
• Environmentally protected electronics for durability.

Product Highlights

This pressure transducer ensures reliable pressure measurement in demanding environments.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: P599VCPS105K

Technical Specifications

• Pressure Range: 0 to 500 psi
• Pressure Port: 1/4 inch SAE 45 F Internal Flare
• Voltage: 0 to 10 VDC
• Housing Material: 304L Stainless Steel
• IP Rating: IP67
• Response Time: 5 msec
• Burst Pressure: 259 bar
• Operating Temperature: -40 Degrees F to 212 Degrees F
• Manufacturers Warranty Length: 3 years
