Johnson Controls P599VCPS105C Pressure Transducer 0 to 500 psi

Product Description

The Johnson Controls P599VCPS105C is a pressure transducer designed to measure a pressure range from zero to five hundred psi. This device features a robust stainless steel construction, making it suitable for various applications including in harsh environments. The P599 series uses a 3-pin Packard connector for electrical connections and provides a voltage output of zero to ten volts DC.

• Pressure range from 0 psi to 500 psi
• Solid 304L stainless steel housing
• IP67 rated for protection against water and dust

Product Highlights

This pressure transducer is ideal for monitoring pressure in corrosive and non-corrosive mediums, including water, refrigerants, and more.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• MPN: P599VCPS105C

Technical Specifications

• Type: Pressure Transmitter
• Range: 0 to 500 psi
• Housing Material: 304L Stainless Steel
• IP Rating: IP67
• Power Required: 12 to 33V DC
• Operating Temperature: -40 Degrees F to 212 Degrees F
• Accuracy: +/-1.50%
• Process Connection: 1/4 in SAE 45 Degrees Flare Male
