Johnson Controls P599RAPS105K Pressure Transducer 0 to 500 psi

Product Description

The Johnson Controls P599RAPS105K Pressure Transducer measures pressure from 0 to 500 psi. It provides a 0.5 to 4.5 VDC ratiometric output signal. This product features a 1/8 inch - 27 NPT external port and includes a Packard connector with a six-foot six-inch wiring harness. This transducer is ideal for monitoring and controlling pressure in various applications.

• Measures pressure within a range of 0 to 500 psi
• Converts pressure into an electrical signal
• Includes a Packard connector with a wiring harness

Product Highlights

The Johnson Controls P599RAPS105K is designed for precise pressure monitoring and control.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: P599RAPS105K

Technical Specifications

• Range Values - Transmitter: 0 to 500
• Max Pressure (PSI): 500 psi
• Output - Transmitter: 0.5 to 4.5V DC
• Process Connection Size - Transmitter: 1/8 inch
• Process Connection Type - Transmitter: MNPT
• Electrical Connections - Transmitter: Packard Connector with six-foot six-inch Wiring Harness
• Operating Temperature - Transmitter: -40 Degrees to 212 Degrees F
• Wetted Materials - Transmitters: 304L Stainless Steel
• Power Required - Transmitters: 4.8 to 5.2V DC
• Accuracy - Transmitter: +/-1.50%
• Housing: 304L Stainless Steel
• Country of Origin: MX
• Model: P599RAPS105K
• Manufacturer Warranty: 1 year
• Transmitter Type: Pressure Transmitter
• Range Units - Transmitter: psi
• Compatible With: All Media Compatible with 304L Stainless Steel, Including Ammonia
• For Use With: Any Corrosive or Non-Corrosive Pressure Medium That is Compatible with 304L Stainless Steel
