Johnson Controls P499VCP-107C Pressure Transducer 0 to 750 PSI 1/4 SAE Flare Internal Thread

Product Description

The Johnson Controls P499VCP-107C is a pressure transducer designed for HVAC and refrigeration applications. This model features a pressure range from zero to seven hundred fifty psig and outputs a signal of zero to ten volts DC. Its design includes a one-fourth inch SAE flare internal thread connection.

• Robust construction for reliability in commercial applications
• Compatible with various media including refrigerants and glycol
• High accuracy with a total error band of 1 percent

Product Highlights

This pressure transducer delivers accurate pressure readings in demanding environments. It is suitable for many applications within HVAC systems.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• MPN: P499VCP-107C

Technical Specifications

• Minimum Pressure: 0 psi
• Maximum Pressure: 750 psi
• Output Signal: 0 to 10 V DC
• Connections: 1/4 in SAE flare internal thread
• Temperature Range: -40 to 185 Degrees F
• Wiring Entry: 1/2 in FNPT
• Material: 17-4PH stainless steel
• IP Rating: IP67
