Johnson Controls M9320-HGA-2 Damper Actuator 24VAC/DC 177 in-lb Torque

Product Description

The JOHNSON CONTROLS M9320-HGA-2 is a non-spring return electric damper actuator designed for HVAC systems. It provides 177 in-lb torque with a 90-second run time and operates on 24 VAC/DC. This direct mount actuator supports floating, on/off, and proportional control signals, making it versatile for various building automation applications. It features a NEMA 5/IP54 enclosure and an operating temperature range of -22°F to 140°F.

• Direct mount design for easy installation without damper linkage.
• Provides 177 in-lb torque with a 90-second run time for precise control.
• Supports floating, on/off, and proportional control signals on 24 VAC/DC power.

Product Highlights

Direct mount damper actuator with 177 in-lb torque, 24 VAC/DC operation, and versatile control signals for HVAC systems.

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: M9320-HGA-2
• Country of Origin: China

Technical Specifications

• Product Type: Damper Actuator
• Run Time: 90 sec
• Torque: 177 in-lb
• Input Voltage: 24V AC/DC
• Stroke Degrees: 35 to 95
• Switch Type: 1 SPDT or 2 SPDT
• Power Rating: 1.3W
• Mounting Type: Direct Mount
• Spring Return: No
• Motor Direction: CW or CCW
• Operating Temperature Range: -22°F to 140°F
• Electrical Connections: 120 in (3.05 m) 19 AWG Plenum Cable
• Supply VA: 5.7 VA
• Enclosure Rating: NEMA 5/IP54
• Application: Building Automation System
• Operating Humidity Range: 5 to 95% RH
• Storage Temperature Range: -40°F to 185°F
• Storage Humidity Range: 5 to 95% RH
• Actuator Type: Non-Spring Return Electric
• Control Signal: On/Off, Floating, 0 (2) to 10 VDC Proportional, or 0 (4) to 20 mA Proportional
• Control Features: Adjustable Span and Offset
• Cable Type: Halogen-Free
