Johnson Controls M9208-BAA-3 Direct Coupled 70 lb-in Spring-Return

Product Description

The Johnson Controls M9208-BAA-3 is an electric actuator designed for use in heating, ventilation, and air conditioning systems. It provides a rated torque of seventy pound-inches and is capable of spring-return operation. This device is suitable for direct coupling to damper shafts and is equipped with integral cables for easy installation.

• On/Off input signal, 120 VAC
• Mechanical spring return system
• Stall detection and double insulated construction

Product Highlights

The actuator features a microprocessor-controlled brushless DC motor that ensures reliable performance across various conditions. Its locking manual override with auto release enhances usability in emergency situations.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: M9208-BAA-3

Technical Specifications

• Power Consumption: 0.5 Amp running, 0.3 Amp holding
• Operating Conditions: -40 F to 140 F (-40 C to 60 C)
• Electrical Connection: 48 in. 18 AWG appliance cable
• Housing: NEMA 2, IP54
• Weight: 4.33 pounds
• Dimensions: 11.6 inches (L) x 6.75 inches (W) x 3.95 inches (H)
