Johnson Controls M9208-AGC-3 Electric Spring-Return Damper Actuator 24V

Product Description

Enhance your HVAC system's performance with the Johnson Controls M9208-AGC-3, an electric spring-return damper actuator designed for robust and reliable operation.

• Provides 70 lb·in rated torque for effective damper control.
• Direct-coupled installation simplifies setup without need for damper linkage.
• Incorporates electronic stall detection to prevent damage during operation.

Product Highlights

This actuator is equipped with a mechanical spring-return system that ensures consistent performance, whether powered or not. Its versatility is further enhanced by the capacity to mount directly to damper shafts ranging from 5/16 to 3/4 inches in diameter using a universal clamp or an optional large shaft coupler kit.

Technical Specifications

• Brand: Johnson Controls
• Model Number: M9208-AGC-3
• Torque: 70 lb·in (8 N·m)
• Control Signal: On/Off, Floating Point
• Voltage: 24V AC
• Switch Type: 2 SPDT
• Dimensions: Height: 6 3/8 inches, Width: 3 7/8 inches, Depth: 2 1/4 inches
