Johnson Controls M9132-GGC-2 Electric Actuator 280 In-lb Non-Spring Return

Product Description

The Johnson Controls M9132-GGC-2 is an electric actuator designed for HVAC systems. This model provides reliable control for dampers and valves, suitable for a variety of industrial applications.

• 280 in-lb torque
• Non-spring return
• Proportional control signal

Product Highlights

This actuator is perfect for managing air flow and fluid control in HVAC systems. It features a self-centering clamping shaft type and proportional control signal, ensuring precise operation.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9132-GGC-2
• Category: HVAC Equipment

Technical Specifications

• Torque: 280 in-lb
• Voltage: 24V AC/DC
• Stroke Angle: 90 degrees
• Switch Type: 2 SPDT
• Shaft Type: Self-Centering Clamping
• Power Consumption: 7.5VA
• Timing: 115 to 205 seconds
• Dimensions: 6 inches height, 4.25 inches width, 2.6875 inches depth
• For Use With: Dampers and Valves
• Includes: Anti-rotation bracket
• Mounting Type: Direct mount
• Ambient Temperature Range: -4 to 122 degrees Fahrenheit
• Electrical Connections: Screw terminals
