Johnson Controls M9132-AGA-2 Electric Non-Spring Return Actuator 24V 32 Nm Torque

Product Description

The M9132-AGA-2 from Johnson Controls is an advanced electric non-spring return actuator designed for efficient and reliable performance in industrial applications. This powerful model delivers up to 32 Nm of torque with simple direct-mount installation compatible with both round and square shafts up to 3.4 and 2.3 inches respectively.

• Compatible with on/off, floating, and proportional control systems.
• Capable of bidirectional operation without a damper linkage.
• Integrated position feedback for accurate control and monitoring.

Product Highlights

This actuator is notably robust, featuring electronic stall detection to prevent overloads and prolong device life. Suitable for a wide array of applications, it can efficiently operate in environments with harsh conditions.

Product Information

Standard Information

• Weight: 4 pounds
• Dimensions: 10 x 6 x 6 inches

Technical Specifications

• Rotation Adjustability: 0 to 90 degrees
• Operating Voltage: 24V AC/DC
• Control Types: On/Off, Floating
• Mounting Type: Direct or Remote
• Connection Type: NPT threaded
• Torque Output: Up to 32 Nm
