Johnson Controls M9124-AGE-2 Electric Non-Spring Return Actuator 24V

Product Description

The Johnson Controls M9124-AGE-2 electric non-spring return actuator is designed for optimal control of air dampers and valves in HVAC systems. This device uses a 24V power source and provides efficient operation with multiple control settings.

• Equipped with 1000 ohm potentiometer for precise positioning.
• Delivers up to 210 lb-in torque for reliable operation.
• Direct-mount design simplifies installation processes.

Product Highlights

This actuator is widely used in the control of HVAC systems, simplifying the installation without the need for a damper linkage. It supports various control inputs including on/off, floating, and proportional controls. Engineered to improve reliability, it features electronic stall detection which deactivates the motor in case of stall conditions, enhancing the component's lifespan.

Product Information

Technical Specifications

• Brand: Johnson Controls
• MPN: M9124-AGE-2
• Torque: 210 lb-in
• Voltage: 24V AC/DC
• Control: On/Off, Floating, Proportional
• Installation: Direct Mount
• Dimensions: Height: 6 inches, Width: 4 1/4 inches, Depth: 2 11/16 inches
• Weight: 4 lbs
