Johnson Controls M9124-AGD-2 Non-Spring Return Motor Actuator

Product Description

The Johnson Controls M9124-AGD-2 is a precision-engineered non-spring return motor actuator, designed for robust and reliable performance in HVAC systems. This actuator operates on 24VAC/DC power and delivers a torque of 210 in-lb, featuring on/off and floating control for effective operation.

• Direct-mount installation for easy setup
• Includes a 135 ohm potentiometer for precise control
• Capable of mechanical adjustment from 0 to 90 degrees

Product Highlights

Engineered for direct coupling, the M9124-AGD-2 facilitates reduced installation times and enhances reliability by eliminating the need for damper linkages. It supports various control inputs to accommodate diverse applications and provides output position feedback for accurate monitoring and adjustment.

Product Information

Standard Information

• Brand: Johnson Controls
• Model: M9124

Technical Specifications

• Power Supply: 24V AC/DC
• Torque: 210 in-lb
• Control Type: On/Off, Floating
• Adjustable Rotation: 0 to 90 degrees
• Installation: Direct Mount
• Feedback Mechanism: 135 ohm potentiometer
