Johnson Controls M9124-AGC-2 Electric Non-Spring Return Actuator 24V 210 lb-in Torque

Product Description

The Johnson Controls M9124-AGC-2 is an electric non-spring return actuator designed for on/off and floating control of dampers and valves in HVAC systems. This model operates on 24V AC/DC power and provides reliable actuation with a torque of 210 lb-in.

• Dual SPDT auxiliary switches offer versatile operation and feedback.
• Direct-mount capability for easy installation without damper linkage.
• Adjustable rotation angle from 0 to 90 degrees in 5-degree increments.

Product Highlights

This advanced actuator features simple direct coupling which reduces installation time and enhances reliability by eliminating the need for damper linkages. It supports various control inputs including on/off, floating, and proportional control, adapting to different technical needs within industrial settings.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9124-AGC-2

Technical Specifications

• Torque: 210 lb-in
• Voltage: 24V AC/DC
• Control Type: On/Off, Floating
• Installation: Direct-Mount, No Damper Linkage Required
• Switch Type: 2 x SPDT
• Rotation Adjustment: 0 to 90 Degrees
