Johnson Controls M9108-JGC-2 Series M9108 Electric Non-Spring-Return Actuator, 100 to 10000 ohm Potentiometer, 8 Nm Torque, 2-SPDT Auxiliary Switch

Product Description

The Johnson Controls M9108-JGC-2 is an electric actuator designed for use with various HVAC applications. This actuator operates on AC or DC twenty-four volts power. It supports on/off, floating, and proportional control. Its compact design allows for easy direct mounting on a damper with a round shaft up to three-quarters of an inch in diameter or a square shaft up to five-eighths of an inch. Installation is straightforward and does not require a damper linkage.

• Delivers up to seventy in-lbs of torque.
• Adjustable rotation angle from zero to ninety degrees in five-degree increments.
• Includes integral auxiliary switches for position feedback.

Product Highlights

This actuator offers reliable performance and ease of installation for HVAC systems.

Product Information

Standard Information

• Manufacturer: Johnson Controls Inc
• Power Supply: 24 VAC/DC

Technical Specifications

• Torque: 70 in-lb
• Stroke: 90 degrees
• Ambient Temperature Range: -4 to 122 degrees Fahrenheit
• Timing: 25 to 50 seconds
• Switch Type: 2 SPDT
• Electrical Connections: Screw terminals
• Mounting Type: Direct mount
• Includes: Anti-rotation bracket
