Johnson Controls M9108-AGE-2 Electric Non-Spring Return Actuator On/Off Floating Control 70 lb-in Torque

Product Description

The M9108-AGE-2 from Johnson Controls is an electric non-spring return actuator designed for precise control of HVAC systems. It features an on/off and floating control mechanism, operating on 24V AC/DC power with a robust 70 lb-in torque output.

• Direct-mount installation for ease and efficiency.
• Features multiple control inputs to accommodate various applications.
• Integrates a 1000 ohm potentiometer for accurate position feedback.

Product Highlights

Johnson Controls M9108-AGE-2 actuator ensures reliable operation with electronic stall detection that prevents motor damage during a stall condition. It offers flexible mounting options, either directly to the damper or via the M9000-5xx Valve Linkage Kits, accommodating both round and square shafts.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9108-AGE-2
• Model: M9108
• Type: Non-Spring Return Actuator

Technical Specifications

• Torque: 70 lb-in
• Voltage: 24V AC/DC
• Control Type: On/Off, Floating
• Configuration: Direct Mount
• Additional Features: 1000 ohm potentiometer, adjustable angle of rotation from 0 to 90 degrees in 5-degree increments, integral auxiliary switches.
