Johnson Controls LC-VAC3000-0 Verasys Application Controller 32 IO

Product Description

The Johnson Controls LC-VAC3000-0 is a Verasys application controller designed with thirty-two input/output points. This controller operates at twenty-four VAC and includes six user inputs, twelve binary inputs, four control outputs, and five relay outputs. It supports BACnet MS/TP, Modbus, and N2 communications through RS-485.

• Integral real-time clock for schedules and monitoring
• Compatible with Johnson Controls and third-party BACnet systems
• Can run as a stand-alone controller

Product Highlights

This product is part of the SMART Equipment Controller family, providing reliable control for various HVAC applications.

Product Information

Standard Information

• Part Number: LC-VAC3000-0
• Brand: Johnson Controls
• Min Order Quantity: 1
• Availability: In Stock

Technical Specifications

• Power Consumption: 20 VA
• Operating Conditions: -4 F To 158 F (-20 C To 70 C), 10 To 95% RH Non-Condensing
• Approvals: cULus Listed, File E107041, CCN PAZX, UL 916
