Johnson Controls JG24B020 Zone Valve Actuator NO 120V

Product Description

The Johnson Controls JG24B020 Zone Valve Actuator is designed for use with HVAC systems requiring a normally open actuator solution. The actuator operates at a voltage of one hundred twenty volts and is essential for regulating water flow in heating applications.

• Type: Normally Open
• Max Water Temperature: 250 Degrees F
• Electrical Connections: Wire Harness

Product Highlights

This actuator delivers reliable performance and is UL listed for safety compliance.

Product Information

Standard Information

• Brand: Johnson Controls
• Product Number: JG24B020

Technical Specifications

• Dimensions: Height 2 3/8 inches, Width 3 1/4 inches, Depth 2 3/8 inches
• Voltage: 120 volts
• Signal Type: On/Off
• Max Water Temp: 250 Degrees F
• Type of Actuator: Normally Open
• Closeoff Pressure Type: Standard
• Agency Compliance: UL listed
• For Use With: Johnson Controls J Series Valves and Erie VT Series Valves
• Country of Origin: United States
