Johnson Controls HE-69135NS-0 Humidity Duct Sensor Surface Mount 0-5V DC

Product Description

The Johnson Controls HE-69135NS-0 Humidity Duct Sensor is a surface-mount duct humidity element used for accurate and reliable humidity sensing in industrial applications. This sensor includes a nickel temperature sensor and operates at 0-5V DC.

• Precise humidity measurements
• Surface mount design
• 0-5V DC input voltage

Product Highlights

This sensor is engineered for HVAC systems, laboratories, and data centers to maintain optimal environmental conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: HE-69135NS-0

Technical Specifications

• Type: Surface Mount
• Frequency: 50 Hz, 60 Hz
• Cable Length: 10 ft
• Sensor Shape: Square
• Input Voltage: 0 to 5V DC
• Overall Depth: 1 1/4 inches
• Overall Width: 3 inches
• Maximum Humidity: 90%
• Minimum Humidity: 10%
• Humidity Accuracy: +/-3% RH for 20% to 80% RH; +/-5% RH for 10% to 20% and 80% to 90% RH
• Maximum Temperature: 140 Degrees F
• Minimum Temperature: 32 Degrees F
• Temperature Accuracy: +/-0.34 Degrees F at 70 Degrees F
• Electrical Connection Type: Hardwired
• Includes Temperature Sensor: Yes
• Maximum Operating Temperature: 140 Degrees F
• Minimum Operating Temperature: 32 Degrees F
