Johnson Controls G-2010-23 Air Pressure Gauge 0-100 PSI Replacement G-2010-23

Product Description

The Johnson Controls G-2010-23 Air Pressure Gauge is designed to offer reliable and precise air pressure measurements in pneumatic control systems. This gauge is suitable for mounting on panels ranging from 1/16 to three quarter inches thick and can be installed using the included U-clamps or via surface mounting.

• Stem mounting simplifies installation on a variety of surfaces.
• Range of 0 to 100 psi allows for diverse application use.
• Equipped with a removable clear plastic lens for maintenance ease.

Product Highlights

Featuring analog pressure readouts alongside an On-Off indicator, the Johnson Controls G-2010-23 is versatile in providing essential data quickly and clearly. The gauge's face prominently displays pressure readings against a white background with metric equivalents in blue, enhancing visibility and readability.

Product Information

Standard Information

• Brand: Johnson Controls
• Pressure Range: 0 to 100 PSI

Technical Specifications

• Size: 2 inch diameter
• Connection Type: 1/8 inch NPT
• Maximum Pressure: 100 PSI
• Mounting Option: Stem/Back
• Material: Industrial-grade components for durability
