Johnson Controls DP140010U11D DPT Low Pressure 0 to 10 in. W.C. 0 VDC To 5 VDC

Product Description

The Johnson Controls DP140010U11D Low Differential Pressure Transducer is designed for HVAC applications, providing precise pressure measurement. Its dead-ended capacitive sensing technology ensures minimal amplification is needed. The device is engineered for accuracy, with capabilities from 0.1 in. W.C. to 25 in. W.C.

• UL 94 V-0 approved fire retardant case
• Low installation costs
• High accuracy of ±1% full-scale

Product Highlights

The DP140010U11D model is ideal for monitoring low pressure in HVAC systems, supporting a range of pressure inputs while ensuring safety and reliability.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: DP140010U11D

Technical Specifications

• Pressure Range: 0 - 10 in. W.C.
• Accuracy: 0.5%
• Output: 0 - 5 VDC
• Operating Temperature: 0°F to 150°F (-18°C to 65°C)
• Storage Temperature: -40°F to 185°F (-40°C to 85°C)
• Maximum Line Pressure: 10 psi, 277 in. W.C.
• Electrical Connections: Removable terminal block
• Case Material: Fire retardant glass-filled polyester
