Johnson Controls D-3244-4 Pneumatic Damper Actuator

Product Description

The Johnson Controls D-3244-4 is a pneumatic damper actuator designed for multiple industrial applications. This actuator operates using an eight to thirteen pounds per square inch (psig) double spring range and has a stroke length of four inches. It comes with a quarter-inch outer diameter (O.D.) barbed fitting air connection. This device includes a swivel mount bracket, clevis, and crank arm.

• Wide operating range for effective control.
• Includes multiple installation accessories.
• Suitable for various applications requiring robust motion control.

Product Highlights

The D-3244-4 combines precision motion control with rugged design, making it ideal for demanding environments.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: D-3244-4

Technical Specifications

• Housing: Die-Cast Aluminum
• Operating Conditions: -20 F to 150 F (-29 C to 66 C)
• Stroke Length: 4 inches
• Spring Pressure Range: 8-13 psig
