Johnson Controls D-3031-4 Pneumatic Damper Actuator 8-13 PSI

Product Description

The Johnson Controls D-3031-4 Pneumatic Damper Actuator is expertly designed for precise damper positioning in small terminal units, featuring a spring range of 8 to 13 PSI. Ideal for applications requiring reliable actuation in condensed spaces, this product stands as a versatile component in heating, ventilation, and air conditioning (HVAC) systems.

• Equipped with a 1 inch stroke and two movable adjustment stops.
• Features a polycarbonate top and body enhancing durability.
• Includes a threaded 5/16 inch diameter piston rod for easy linkage attachment.

Product Highlights

This actuator is the go-to replacement for the D-160 and D-251 #2S models, ensuring a seamless fit and exceptional performance. It offers flexible mounting options, whether swivel or rigid, and accommodates optional mounting kits for comprehensive application coverage.

Product Information

Standard Information

• Model: D-3032
• Weight: 0.60 lbs

Technical Specifications

• Pressure Range: 8-13 PSI
• Stroke Length: 1 inch
• Adjustment Increments: 1/8 inch
