Johnson Controls CSDSC-S75050L Current Sensing Relay Solid Core 0.50A Replacement CSDSC-S75050L

Product Description

The Johnson Controls CSDSC-S75050L is a high-performance current sensing relay designed for reliable monitoring and control of electrical loads. It features a solid core and a compact design suitable for surface mounting.

• Adjustable trip points from 0.75 to 50 amps for versatile applications
• Self-powered operation with a built-in LED status indicator for easy diagnostics
• Robust terminal strip electrical connection for secure wiring

Product Highlights

This relay is equipped with SPST-NO contact form that supports up to 1 amp at 30 volts, ensuring high reliability in various electrical environments. Its solid state output provides excellent response times and durability.

Product Information

Technical Specifications

• Type: Current Sensing Relay
• Contact Rating: 1 A @ 30V AC/DC
• Core Type: Solid
• Mounting: Surface
• Input Voltage: Self Powered
• Body Dimensions: 1.6 inches depth, 0.97 inches width, 2.26 inches height
• Wire Gauge: 14 AWG, 24 AWG
• Sensing Hole Diameter: 0.51 inches
• Status Indicator: LED
• Adjustment Type: Switch
• Frequency: 50/60 Hz
• Standards: CE Certified, UL Listed
