Johnson Controls C450RBN-3 Reset Control Module 24-240 VAC (1stg)

Product Description

Johnson Controls C450RBN-3 is a reset control module for HVAC and temperature control systems that provides single-stage reset functionality. The module accepts 24-240 VAC input, supports a 0.5�3.0 A current range, and operates from -40�F to 122�F. It offers an LCD four-button touchpad user interface, analog output and one SPDT output relay, accepts 0�5 VDC sensor inputs, and can include A99BC temperature sensors and clock backup.

• Input Voltage: 24-240 VAC; Current Range: 0.5�3.0 A; Operating Temperature: -40�F to 122�F
• Outputs and I/O: one SPDT output relay, analog output; accepts 0�5 VDC input signals for sensors
• User interface and timing: LCD four-button touchpad UI; includes A99BC-25 and A99BC-300 temperature sensors; �4 minutes/year clock accuracy with 12-hour backup

Product Highlights

Single-stage reset control module with relay and analog I/O for HVAC and industrial temperature control

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: C450RBN-3

Technical Specifications

• Brand: Johnson Controls
• MPN: C450RBN-3
• Type: Reset Control Module (1stg)
• Model Family: System 450
• Input Voltage: 24-240 VAC
• Output Current: 0.5-3.0 A
• Operating Temperature: -40�F to 122�F
• User Interface: LCD with four-button touchpad
• Outputs: One SPDT output relay; analog output
• Inputs: 0-5 VDC sensor inputs
• Included Sensors: A99BC-25 (9 ft lead) and A99BC-300 (10 in lead) temperature sensors with silicon leads
• Clock Accuracy: �4 minutes per year
• Clock Backup: 12-hour backup power
• Mounting Type: Surface mount
