Johnson Controls A421AED-01C Penn Series A421 Line-Voltage Type 4X Electronic Temperature Control IP67 Sensor

Product Description

The Johnson Controls A421AED-01C Penn Series A421 is a line-voltage type 4X electronic temperature control designed for industrial environments. This model includes an IP67 weathertight enclosure and a temperature sensor featuring a 9-7/8 inch cable.

• Backlit LCD screen for easy temperature reading
• SPDT off-cycle defrost control for effective temperature management
• Enclosure rated IP66 for protection against harsh conditions

Product Highlights

This electronic temperature control is equipped with a bright backlit LCD, adjustable temperature set points, and a compact design for easy installation. It is suitable for heating and cooling applications, featuring basic and advanced programming menus for easy setup.

Product Information

Standard Information

• Manufacturer: Johnson Controls Inc
• Brand: Johnson Controls
• Model: A421AED-01C

Technical Specifications

• Voltage: 120/240 VAC
• Control Range: -40 to 212 degrees F
• Differential: 1 to 30 degrees F
• Sensing Bulb Diameter: 1/4 inch
• Sensing Bulb Length: 2 inches
• Enclosure Type: NEMA 4X
• Full Load Amps at 120VAC: 16A
• Full Load Amps at 240VAC: 8A
