Johnson Controls T-5210-1113 Pneumatic Temperature Transmitter

Product Description

Explore the Johnson Controls T-5210-1113, a state-of-the-art pneumatic temperature transmitter. It is designed to precisely measure temperature and convert these measurements into an accurate air pressure signal, which is then transmitted to pneumatic systems for comprehensive temperature management.

• Accurately measures temperatures from -40 to 160 degrees Fahrenheit.
• Equipped with a 4 feet copper bulb and capillary for precise sensing.
• Designed to perform in any position and optimized for various mounting applications including ductwork and walls.

Product Highlights

This transmitter is ideal for applications requiring reliable temperature monitoring and control in HVAC systems, industrial settings, and scientific research facilities. It ensures a proportional relationship between the measured temperature and the output signal, enhancing system response and stability.

Technical Specifications

• Temperature Range: -40 to 160 degrees Fahrenheit
• Capillary Length: 4 feet
• Output Pressure Range: 3 to 15 psi
• Connection Type: 1/8 inch NPT barbed fitting for 5/32 inch or 1/4 inch OD polytubing
• Element Type: Copper bulb
• Operating Positions: Can be mounted in any position
• Required Air: Needs a 0.007 inch restricted supply
