JOHNS MANVILLE INS-LIN-1X471/2 JOHNS MANVILLE LINACOUSTIC RC DUCT LINER 1 IN REPLACEMENT MPN

Product Description

JOHNS MANVILLE Linacoustic RC duct liner with MPN INS-LIN-1X471/2 is designed for use in HVAC systems. It serves as a flexible insulation material for sheet metal ducts. This product is made from durable glass fibers that are bonded with a thermosetting resin to offer both thermal and acoustical benefits. The airstream surface utilizes a reinforced coating system, featuring a Permacote acrylic coating along with a flexible glass mat. This attribute provides a smooth surface that resists dust, dirt, and microbial growth.

• Improves indoor air quality by managing temperature and sound.
• Resistant to dirt and dust due to the durable Permacote coating.
• Formulated to inhibit microbial growth with an EPA-registered agent.

Product Highlights

This duct liner enhances the performance of HVAC systems by ensuring thermal insulation and sound dampening, making it a valuable addition to heating and cooling applications.

Product Information

Standard Information

• Application: For Air Conditioning, Heating and Ventilating Systems
• Item Name: Fiberglass Duct Liner

Technical Specifications

• Flame Spread Index: 25
• Insulation Thickness: 1 inch
• Length: 100 feet
• Material: Fiberglass
• Maximum Air Velocity: 6000 feet per minute
• R-Value: 4.2
• Smoke Developed Index: 50
• Temperature Rating: 250 degrees Fahrenheit
• Thermal Conductivity: 0.24 Btu-in/hr-sq-ft-deg F
• Treatment: Permacote Acrylic Coating
• Water Vapor Sorption: >=6%
• Width: 47.5 inches
