John Guest 24502 Pressure Reducing Valve 3/4 in Sweat

Product Description

The JOHN GUEST 24502 is a 3/4-inch pressure reducing valve featuring sweat (solder) end connections and integral check valves. Designed for residential and light commercial plumbing systems, this valve reduces incoming supply pressure to a safe, manageable downstream level while the built-in check valves prevent backflow within the same assembly. Licensed plumbers and water system installers are the primary trade for this component. The Hg110-D configuration indicates a valve body suited for standard domestic water service applications where pressure regulation and backflow protection are required in a compact, single-unit form.

This valve is suited for installation on cold water supply lines where high incoming pressure must be stepped down before distribution to fixtures, appliances, or hydronic equipment. The sweat connection style requires soldering to copper pipe, making this a common choice in new construction and retrofit plumbing projects. Its integral check valves eliminate the need for a separately installed check valve in many configurations, simplifying the rough-in.

Key Features

• 3/4-inch sweat (solder) end connections for direct copper pipe installation
• Integral check valves built into the valve body for backflow prevention
• Hg110-D valve configuration for residential and light commercial water service
• Single-assembly design combines pressure regulation and check valve functions
• Manufactured under the RWC family of brands, which includes Cash Acme and John Guest product lines

Compatibility

Designed as an OEM-style replacement or new-installation pressure reducing valve for residential and light commercial copper pipe plumbing systems using 3/4-inch sweat connections.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the International Plumbing Code (IPC). Shut off the main water supply and relieve system pressure before cutting into any existing line. Sweat connections require proper flux application, a propane or MAPP torch, and lead-free solder per current code requirements. Do not apply torch heat directly to the valve body; solder the fittings with the valve protected from excess heat to avoid damage to internal components.

Technical Specifications

• Connection Size: 3/4 inches
• Connection Type: Sweat (Solder)
• Valve Configuration: Hg110-D
• Integral Check Valves: Yes

Standard Information

• Brand: JOHN GUEST
• Manufacturer Part Number: 24502
