Jet BA9-1017555 Beveling Machine 1.5 Hp 110V

Product Description

The JET BA9-1017555 is a bench-mount beveling and chamfering machine built for metalworking shops and fabrication environments. Powered by a 1.5 HP motor running on 110-volt single-phase power, this machine delivers consistent chamfers up to 6mm on plate edges and structural stock. The adjustable bevel angle ranges from 15 to 45 degrees, giving fabricators precise control over edge prep for welding, finishing, or assembly applications. A 5-blade cutting wheel produces a clean, smooth finish on each pass. Licensed metalworkers, welders, and fabricators are the primary installers and operators of this machine.

The BA9-1017555 is suited for light industrial and production shop use where repeatable edge beveling is required. Its two precision-machined tables keep workpieces aligned throughout the cut, reducing rework and improving weld joint quality. The bench-top mounting footprint makes it practical for shops where floor space is limited. It is commonly used in steel fabrication, shipbuilding prep work, pressure vessel fabrication, and general metal plate processing.

Key Features

• 1.5 HP motor on 110-volt single-phase power for broad outlet compatibility
• Chamfer capacity up to 6mm on any edge
• Adjustable bevel angle from 15 to 45 degrees
• 5-blade cutting wheel for smooth, consistent finish
• Two precision-machined tables for accurate material alignment
• Bench-top mount design conserves floor space
• 1-year parts warranty with lifetime technical support

Compatibility

Designed as a bench-mount beveling and chamfering machine for use in metal fabrication applications requiring edge preparation on plate and structural stock.

Installation Notes

Installation is performed by a qualified fabricator or maintenance technician. Before mounting or servicing, disconnect power at the source and verify the circuit matches the machine voltage and amperage requirements. Secure the unit firmly to a stable bench surface using appropriate hardware before operation. Follow all applicable OSHA machine guarding requirements and the manufacturer instructions for blade changes and angle adjustments.

Technical Specifications

• Motor: 1.5 HP
• Voltage: 110 volts single-phase
• Maximum Chamfer: 6mm
• Bevel Angle Range: 15 to 45 degrees
• Cutting Wheel Blades: 5
• Weight: 150 pounds
• Mount Type: Bench top
• Warranty: 1-year parts, lifetime technical support

Standard Information

• Brand: JET
• Manufacturer Part Number: BA9-1017555
